P50+02 B 600M

P50+02 B 600M · Product image

Image may differ from product. See technical specifications for details.

P50+02 B 600M · Technical drawing

Brand
QIBR
Housing model
P50
Bearing model
02 B 600M
Alternative brand
Cooper
Rolling element type
Roller
Measurement system
Metric
Inner diameter
600 mm
Total height
1345 mm
Bolt size
M42
Number of holes
8
Distance of holes
984~1036 mm
Total length
1524 mm
Location of centre
673 mm
Total width
382 mm
Permissible axial displacement
18-27 mm
Height
92 mm
Number of rolling element rows
Single row
Bearing type
Plummer Bearing Units
Bearing clearances (radial)
CN/C2
Load direction
Radial
Lubrication
Grease
Rolling element material
52100
Temperature
-20 ℃ to +80 ℃
Seal type
Closed Type
Outer diameter
838.20 mm
Width of inner ring
214.0 mm
Width of outer ring
119.1 mm
Basic dynamic load rating (axial)
300.0 kN
Basic dynamic load rating (radial)
2905 kN
Basic static load rating (radial)
5992 kN
Limiting speed
290 rpm
Bearing weight
381.0 kg
Weight of bearing housing
1050.0 kg

Inquiry for P50+02 B 600M

Tell us your operating requirements and required quantity.

Description

Split Bearing Units are pre-assembled systems combining split bearings (cylindrical/spherical rollers) with split housings (Plummer blocks), designed to enable rapid installation and maintenance without shaft disassembly. Ideal for heavy industries where downtime is costly.

QIBR - P50+02 B 600M Split Bearing Units Advantages and Applications

QIBR - P50+02 B 600M Split Bearing Units Characteristics
