P01+01 B 35M

P01+01 B 35M · Product image

Image may differ from product. See technical specifications for details.

P01+01 B 35M · Technical drawing

Brand
QIBR
Housing model
P01
Bearing model
01 B 35M
Alternative brand
Cooper
Rolling element type
Roller
Measurement system
Metric
Inner diameter
35 mm
Total height
138 mm
Bolt size
M12
Number of holes
2
Distance of holes
172～192 mm
Total length
228 mm
Location of centre
60 mm
Total width
60mm
Permissible axial displacement
3.5～5.5 mm
Height
22 mm
Number of rolling element rows
Single row
Bearing type
Plummer Bearing Units
Bearing clearances (radial)
CN/C2
Load direction
Radial
Lubrication
Grease
Rolling element material
52100
Temperature
-20 ℃ to +80 ℃
Seal type
Closed Type
Outer diameter
84.14 mm
Width of inner ring
50.1 mm
Width of outer ring
23.8 mm
Basic dynamic load rating (axial)
3.2 kN
Basic dynamic load rating (radial)
67 kN
Basic static load rating (radial)
67 kN
Limiting speed
5400 rpm
Bearing weight
1.2 kg
Weight of bearing housing
2.5 kg

Inquiry for P01+01 B 35M

Tell us your operating requirements and required quantity.

Description

Split Bearing Units are pre-assembled systems combining split bearings (cylindrical/spherical rollers) with split housings (Plummer blocks), designed to enable rapid installation and maintenance without shaft disassembly. Ideal for heavy industries where downtime is costly.

QIBR - P01+01 B 35M Split Bearing Units Advantages and Applications

QIBR - P01+01 B 35M Split Bearing Units Characteristics
