TS684
- Brand
- QIBR
- Measurement system
- Imperial
- Pitch
- 6 inch
- Number of teeth
- 84
- Outer diameter
- 14.333 inch
- Gear P.C.D
- 14.000 inch
- Inner diameter
- 1 1/4~2 13/16 inch
- Tooth width
- 2 inch
- Size
- 5 inch
- Width
- 1 1/2 inch
- Material
- Steel
- Weight
- 42.80 lbs
- Pressure angle
- 20°
Tell us your operating requirements and required quantity.
Description
QIBR - TS684 Gears Advantages and Applications
TS684 Gears, simple structure, high precision, high load-bearing capacity, Pitch is 6 inch, Outer diameter is 14.333 inch, Weight is 42.80 lbs. It is suitable for the transmission system of packaging machines, printing machines and medical equipment, etc. It is the most widely used in working conditions with high precision requirements.
QIBR - TS684 Gears Characteristics
TS684 Gears, high reliability, long life, easy installation and maintenance. TS684 Gears, can withstand radial load, certain axial load and overturning moment, suitable for mechanical equipment with high precision requirements.
Features & benefits
Spur gears are key components in mechanical transmission, transmitting power and motion through teeth meshing. They provide precise speed control and torque conversion and are widely used in various mechanical devices.
