Spur Gears | QIBR Bearings

Specifications

Standard: GB,ASTM/AISI,ГОСТ,BS,JIS,NF,DIN / VDEh
Material: 42CrMo, 50Mn
Pitch diameter: 4-36 inch
Outer diameter: 4.666-36.5 inch
Weight: 12-140 lbs
Brand: QIBR/OEM/Neutral
Package: QIBR/Standard Industrial Package/OEM
Applications: suitable for the transmission system of packaging machines, printing machines and medical equipment, etc. It is the most widely used in working conditions with high precision requirements.

QIBR Model Selection
No.	Product model	Outer diameter	Weight	Number of teeth	Gear P.C.D	Pitch
1	C10100	10.200 inch	10.30 lbs	100	10.000 inch	10 inch
2	C10105	10.700 inch	10.40 lbs	105	10.500 inch	10 inch
3	C10110	11.200 inch	10.00 lbs	110	11.000 inch	10 inch
4	C10112	11.400 inch	10.20 lbs	112	11.200 inch	10 inch
5	C10120	12.200 inch	11.10 lbs	120	12.000 inch	10 inch
6	C10130	13.200 inch	13.40 lbs	130	13.000 inch	10 inch
7	C10140	14.200 inch	30.80 lbs	140	14.000 inch	10 inch
8	C10150	15.200 inch	33.00 lbs	150	15.000 inch	10 inch
9	C10160	16.200 inch	38.30 lbs	160	16.000 inch	10 inch
10	C10180	18.200 inch	43.60 lbs	180	18.000 inch	10 inch
11	C1060	6.200 inch	4.30 lbs	60	6.000 inch	10 inch
12	C1064	6.600 inch	5.60 lbs	64	6.400 inch	10 inch
13	C1065	6.700 inch	5.60 lbs	65	6.500 inch	10 inch
14	C1070	7.200 inch	5.90 lbs	70	7.000 inch	10 inch
15	C1072	7.500 inch	6.30 lbs	72	7.200 inch	10 inch
16	C1075	7.700 inch	6.70 lbs	75	7.500 inch	10 inch
17	C1080	8.200 inch	7.00 lbs	80	8.000 inch	10 inch
18	C1084	8.600 inch	6.90 lbs	84	8.400 inch	10 inch
19	C1085	8.700 inch	7.30 lbs	85	8.500 inch	10 inch
20	C1090	9.200 inch	7.60 lbs	90	9.000 inch	10 inch
21	C1095	9.700 inch	8.10 lbs	95	9.500 inch	10 inch
22	C1096	9.800 inch	8.10 lbs	96	9.600 inch	10 inch
23	C12102	8.666 inch	5.9 lbs	102	8.500 inch	12 inch
24	C12108	9.166 inch	6.4 lbs	108	9.000 inch	12 inch
25	C12112	9.500 inch	6.4 lbs	112	9.333 inch	12 inch
