TS590

TS590 · Product image

Image may differ from product. See technical specifications for details.

TS590 · Technical drawing

Brand
QIBR
Measurement system
Imperial
Pitch
5 inch
Number of teeth
90
Outer diameter
18.400 inch
Gear P.C.D
18.000 inch
Inner diameter
13/16~3 1/8 inch
Tooth width
2 1/2 inch
Size
5 1/4 inch
Width
1 1/4 inch
Material
Steel
Weight
59.70 lbs
Pressure angle
20°

Inquiry for TS590

Tell us your operating requirements and required quantity.

Description

QIBR - TS590 Gears Advantages and Applications

TS590 Gears, simple structure, high precision, high load-bearing capacity, Pitch is 5 inch, Outer diameter is 18.400 inch, Weight is 59.70 lbs. It is suitable for the transmission system of packaging machines, printing machines and medical equipment, etc. It is the most widely used in working conditions with high precision requirements.

QIBR - TS590 Gears Characteristics

TS590 Gears, high reliability, long life, easy installation and maintenance. TS590 Gears, can withstand radial load, certain axial load and overturning moment, suitable for mechanical equipment with high precision requirements.
