TS5110

TS5110 · Product image

Image may differ from product. See technical specifications for details.

TS5110 · Technical drawing

Brand
QIBR
Measurement system
Imperial
Pitch
5 inch
Number of teeth
110
Outer diameter
22.400 inch
Gear P.C.D
22.000 inch
Inner diameter
15/16~3 1/4 inch
Tooth width
2 1/2 inch
Size
5 3/4 inch
Width
1 1/2 inch
Material
Steel
Weight
72.30 lbs
Pressure angle
20°

Inquiry for TS5110

Tell us your operating requirements and required quantity.

Description

QIBR - TS5110 Gears Advantages and Applications

TS5110 Gears, simple structure, high precision, high load-bearing capacity, Pitch is 5 inch, Outer diameter is 22.400 inch, Weight is 72.30 lbs. It is suitable for the transmission system of packaging machines, printing machines and medical equipment, etc. It is the most widely used in working conditions with high precision requirements.

QIBR - TS5110 Gears Characteristics

TS5110 Gears, high reliability, long life, easy installation and maintenance. TS5110 Gears, can withstand radial load, certain axial load and overturning moment, suitable for mechanical equipment with high precision requirements.
