S580
- Brand
- QIBR
- Measurement system
- Imperial
- Pitch
- 5 inch
- Number of teeth
- 80
- Outer diameter
- 16.400 inch
- Gear P.C.D
- 16.000 inch
- Inner diameter
- 1 3/16~3 1/8 inch
- Tooth width
- 1 3/4 inch
- Size
- 5 inch
- Width
- 1 1/4 inch
- Material
- Steel
- Weight
- 57.00 lbs
- Pressure angle
- 14.5°
Tell us your operating requirements and required quantity.
Description
QIBR - S580 Gears Advantages and Applications
S580 Gears, simple structure, high precision, high load-bearing capacity, Pitch is 5 inch, Outer diameter is 16.400 inch, Weight is 57.00 lbs. It is suitable for the transmission system of packaging machines, printing machines and medical equipment, etc. It is the most widely used in working conditions with high precision requirements.
QIBR - S580 Gears Characteristics
S580 Gears, high reliability, long life, easy installation and maintenance. S580 Gears, can withstand radial load, certain axial load and overturning moment, suitable for mechanical equipment with high precision requirements.
Features & benefits
Spur gears are key components in mechanical transmission, transmitting power and motion through teeth meshing. They provide precise speed control and torque conversion and are widely used in various mechanical devices.
