S20120

S20120 · Product image

Image may differ from product. See technical specifications for details.

S20120 · Technical drawing

Brand
QIBR
Measurement system
Imperial
Pitch
20 inch
Number of teeth
120
Outer diameter
6.100 inch
Gear P.C.D
6.000 inch
Inner diameter
1/2~1 inch
Tooth width
3/8 inch
Size
1 3/4 inch
Width
1/2 inch
Material
Steel
Weight
3.24 lbs
Pressure angle
14.5°

Inquiry for S20120

Tell us your operating requirements and required quantity.

Description

QIBR - S20120 Gears Advantages and Applications

S20120 Gears, simple structure, high precision, high load-bearing capacity, Pitch is 20 inch, Outer diameter is 6.100 inch, Weight is 3.24 lbs. It is suitable for the transmission system of packaging machines, printing machines and medical equipment, etc. It is the most widely used in working conditions with high precision requirements.

QIBR - S20120 Gears Characteristics

S20120 Gears, high reliability, long life, easy installation and maintenance. S20120 Gears, can withstand radial load, certain axial load and overturning moment, suitable for mechanical equipment with high precision requirements.
