C536
- Brand
- QIBR
- Measurement system
- Imperial
- Pitch
- 5 inch
- Number of teeth
- 36
- Outer diameter
- 7.600 inch
- Gear P.C.D
- 7.200 inch
- Inner diameter
- 1 3/16~2 1/16 inch
- Tooth width
- 1 3/4 inch
- Size
- 3 1/4 inch
- Width
- 1 1/4 inch
- Material
- Cast Iron
- Weight
- 15.50 lbs
- Pressure angle
- 14.5°
Tell us your operating requirements and required quantity.
Description
QIBR - C536 Gears Advantages and Applications
C536 Gears, simple structure, high precision, high load-bearing capacity, Pitch is 5 inch, Outer diameter is 7.600 inch, Weight is 15.50 lbs. It is suitable for the transmission system of packaging machines, printing machines and medical equipment, etc. It is the most widely used in working conditions with high precision requirements.
QIBR - C536 Gears Characteristics
C536 Gears, high reliability, long life, easy installation and maintenance. C536 Gears, can withstand radial load, certain axial load and overturning moment, suitable for mechanical equipment with high precision requirements.
Features & benefits
Spur gears are key components in mechanical transmission, transmitting power and motion through teeth meshing. They provide precise speed control and torque conversion and are widely used in various mechanical devices.
