C535
- Brand
- QIBR
- Measurement system
- Imperial
- Pitch
- 5 inch
- Number of teeth
- 35
- Outer diameter
- 7.400 inch
- Gear P.C.D
- 7.000 inch
- Inner diameter
- 1 3/16~2 1/16 inch
- Tooth width
- 1 3/4 inch
- Size
- 3 1/4 inch
- Width
- 1 1/4 inch
- Material
- Cast Iron
- Weight
- 16.90 lbs
- Pressure angle
- 14.5°
Tell us your operating requirements and required quantity.
Description
QIBR - C535 Gears Advantages and Applications
C535 Gears, simple structure, high precision, high load-bearing capacity, Pitch is 5 inch, Outer diameter is 7.400 inch, Weight is 16.90 lbs. It is suitable for the transmission system of packaging machines, printing machines and medical equipment, etc. It is the most widely used in working conditions with high precision requirements.
QIBR - C535 Gears Characteristics
C535 Gears, high reliability, long life, easy installation and maintenance. C535 Gears, can withstand radial load, certain axial load and overturning moment, suitable for mechanical equipment with high precision requirements.
Features & benefits
Spur gears are key components in mechanical transmission, transmitting power and motion through teeth meshing. They provide precise speed control and torque conversion and are widely used in various mechanical devices.
