C10150
- Brand
- QIBR
- Measurement system
- Imperial
- Pitch
- 10 inch
- Number of teeth
- 150
- Outer diameter
- 15.200 inch
- Gear P.C.D
- 15.000 inch
- Inner diameter
- 1 ~1 11/16 inch
- Tooth width
- 1 inch
- Size
- 2 3/4 inch
- Width
- 1 inch
- Material
- Cast Iron
- Weight
- 33.00 lbs
- Pressure angle
- 14.5°
Tell us your operating requirements and required quantity.
Description
QIBR - C10150 Gears Advantages and Applications
C10150 Gears, simple structure, high precision, high load-bearing capacity, Pitch is 10 inch, Outer diameter is 15.200 inch, Weight is 33.00 lbs. It is suitable for the transmission system of packaging machines, printing machines and medical equipment, etc. It is the most widely used in working conditions with high precision requirements.
QIBR - C10150 Gears Characteristics
C10150 Gears, high reliability, long life, easy installation and maintenance. C10150 Gears, can withstand radial load, certain axial load and overturning moment, suitable for mechanical equipment with high precision requirements.
Features & benefits
Spur gears are key components in mechanical transmission, transmitting power and motion through teeth meshing. They provide precise speed control and torque conversion and are widely used in various mechanical devices.
