P37+02 B 1100

P37+02 B 1100 · Product image

Image may differ from product. See technical specifications for details.

P37+02 B 1100 · Technical drawing

Brand
QIBR
Housing model
P37
Bearing model
02 B 1100
Alternative brand
Cooper
Rolling element type
Roller
Measurement system
Imperial
Inner diameter
11 inch
Total height
760 mm
Bolt size
1 1/4UNC
Number of holes
8
Distance of holes
514~554 mm
Total length
914 mm
Location of centre
378 mm
Total width
330 mm
Permissible axial displacement
14～29 mm
Height
60 mm
Number of rolling element rows
Single row
Bearing type
Plummer Bearing Units
Bearing clearances (radial)
CN/C2
Load direction
Radial
Lubrication
Grease
Rolling element material
52100
Temperature
-20 ℃ to +80 ℃
Seal type
Closed Type
Outer diameter
463.55 mm
Width of inner ring
186.0 mm
Width of outer ring
101.6 mm
Basic dynamic load rating (axial)
114.0 kN
Basic dynamic load rating (radial)
1367 kN
Basic static load rating (radial)
2145 kN
Limiting speed
670 rpm
Bearing weight
86.0 kg
Weight of bearing housing
292.0 kg

Inquiry for P37+02 B 1100

Tell us your operating requirements and required quantity.

Description

Split Bearing Units are pre-assembled systems combining split bearings (cylindrical/spherical rollers) with split housings (Plummer blocks), designed to enable rapid installation and maintenance without shaft disassembly. Ideal for heavy industries where downtime is costly.

QIBR - P37+02 B 1100 Split Bearing Units Advantages and Applications

QIBR - P37+02 B 1100 Split Bearing Units Characteristics
