P25+01 B 2000
- Brand
- QIBR
- Housing model
- P25
- Bearing model
- 01 B 2000
- Alternative brand
- Cooper
- Rolling element type
- Roller
- Measurement system
- Imperial
- Inner diameter
- 20 inch
- Total height
- 980 mm
- Bolt size
- 1 3/4UNC
- Number of holes
- 4
- Distance of holes
- 824~864 mm
- Total length
- 1092 mm
- Location of centre
- 489 mm
- Total width
- 304 mm
- Permissible axial displacement
- 11～23 mm
- Height
- 76 mm
- Number of rolling element rows
- Single row
- Bearing type
- Plummer Bearing Units
- Bearing clearances (radial)
- CN/C2
- Load direction
- Radial
- Lubrication
- Grease
- Rolling element material
- 52100
- Temperature
- -20 ℃ to +80 ℃
- Seal type
- Closed Type
- Outer diameter
- 654.05 mm
- Width of inner ring
- 168.0 mm
- Width of outer ring
- 80.2 mm
- Basic dynamic load rating (axial)
- 138.0 kN
- Basic dynamic load rating (radial)
- 1213 kN
- Basic static load rating (radial)
- 2593 kN
- Limiting speed
- 360 rpm
- Bearing weight
- 136.0 kg
- Weight of bearing housing
- 402.0 kg
Tell us your operating requirements and required quantity.
Description
Split Bearing Units are pre-assembled systems combining split bearings (cylindrical/spherical rollers) with split housings (Plummer blocks), designed to enable rapid installation and maintenance without shaft disassembly. Ideal for heavy industries where downtime is costly.
QIBR - P25+01 B 2000 Split Bearing Units Advantages and Applications
QIBR - P25+01 B 2000 Split Bearing Units Characteristics
Features & benefits
Plummer bearing units feature a split housing design for easy installation without shaft disassembly, ideal for heavy-load applications like mining and cement. Their self-aligning capability (±2-3°) compensates for shaft misalignment, while pre-lubricated bearings reduce maintenance needs. These robust units come in standard SNL/SAF series for interchangeability with major brands.
