Interchangeable Bearing Units-Metric

Specifications

Standard: GB,ASTM/AISI,ГОСТ,BS,JIS,NF,DIN / VDEh
Material: High Carbon Chromium Bearing Steel/Grey Iron or Ductile Iron/Bearing steel GCr15
Brand: QIBR/OEM/Neutral
Package: QIBR/Standard Industrial Package/OEM
Outer diameter: 60~300mm
Applications: Automotive Industry, Material Handling Equipment, Construction Machinery, Agricultural Equipment, etc

QIBR Model Selection
No.	Product model	Bolt size	Inner diameter	Total length	Height	Total width
1	SDC3134+01 B 150M	M24	150 mm	510 mm	401 mm	174 mm
2	SDC3136+01 B 160M	M24	160 mm	530 mm	396 mm	192 mm
3	SDC3138+01 B 170M	M24	170 mm	560 mm	425 mm	200 mm
4	SDC3140+01 B 180M	M30	180 mm	600 mm	445 mm	200 mm
5	SDC3144+01 B 200M	M30	200 mm	640 mm	467 mm	200 mm
6	SDC3148+01 B 220M	M30	220 mm	700 mm	510 mm	216 mm
7	SDC3152+01 B 240M	M36	240 mm	770 mm	552 mm	222 mm
8	SDC3156+01 B 260M	M36	260 mm	790 mm	591 mm	232 mm
9	SDC3160+01 B 280M	M36	280 mm	830 mm	611 mm	232 mm
10	SDC3164+01 B 300M	M36	300 mm	880 mm	663 mm	248 mm
11	SNC513+01E B 60M	M16	60 mm	280 mm	180 mm	104 mm
12	SNC515+01E B 65M	M16	65 mm	280 mm	180 mm	104 mm
13	SNC516+01E B 70M	M20	70 mm	315 mm	208 mm	114 mm
14	SNC517+01E B 75M	M20	75 mm	315 mm	208 mm	114 mm
15	SNC518+01E B 80M	M20	80 mm	345 mm	240 mm	136 mm
16	SNC519+01E B 85M	M20	85 mm	345 mm	252 mm	136 mm
17	SNC520+01E B 90M	M24	90 mm	380 mm	252 mm	136 mm
18	SNC522+01E B 100M	M24	100 mm	420 mm	272 mm	134 mm
19	SNC524+01 B 110M	M24	110 mm	410 mm	310 mm	142 mm
20	SNC526+01 B 115M	M24	115 mm	450 mm	320 mm	142 mm
21	SNC528+01 B 125M	M30	125 mm	500 mm	360 mm	156 mm
22	SNC530+01 B 135M	M30	135 mm	530 mm	386 mm	168 mm
23	SNC532+01 B 140M	M30	140 mm	558 mm	391 mm	168 mm
