01 H 110M TRIPLE BOSS+01 B 110M EX

01 H 110M TRIPLE BOSS+01 B 110M EX · Product image

Image may differ from product. See technical specifications for details.

01 H 110M TRIPLE BOSS+01 B 110M EX · Technical drawing

Brand
QIBR
Housing model
01 H 110M TRIPLE BOSS
Bearing model
01 B 110M EX
Alternative brand
Cooper
Rolling element type
Roller
Measurement system
Metric
Outer diameter
290 mm
Inner diameter
110 mm
Total width
170 mm
Bolt size
M36
Width
/
Size
/
Location of centre
140 mm
Number of rolling element rows
Single row
Bearing type
Hanger bearing units
Bearing clearances (radial)
CN/C2
Weight of bearing housing
30.0 kg
Load direction
Radial
Lubrication
Grease
Rolling element material
52100
Temperature
-20 ℃ to +80 ℃
Seal type
Closed Type

Inquiry for 01 H 110M TRIPLE BOSS+01 B 110M EX

Tell us your operating requirements and required quantity.

Description

Split Bearing Units are pre-assembled systems combining split bearings (cylindrical/spherical rollers) with split housings (Plummer blocks), designed to enable rapid installation and maintenance without shaft disassembly. Ideal for heavy industries where downtime is costly.

QIBR - 01 H 110M TRIPLE BOSS+01 B 110M EX Split Bearing Units Advantages and Applications

QIBR - 01 H 110M TRIPLE BOSS+01 B 110M EX Split Bearing Units Characteristics
