01 H 403+01 B 403 EX
- Brand
- QIBR
- Housing model
- 01 H 403
- Bearing model
- 01 B 403 EX
- Alternative brand
- Cooper
- Rolling element type
- Roller
- Measurement system
- Imperial
- Outer diameter
- 232 mm
- Inner diameter
- 4 3/16 inch
- Total width
- 156 mm
- Bolt size
- M36
- Width
- 76 mm
- Size
- 226 mm
- Location of centre
- 140 mm
- Number of rolling element rows
- Single row
- Bearing type
- Hanger bearing units
- Weight of bearing housing
- 16.4 kg
- Load direction
- Radial
- Bearing clearances (radial)
- CN/C2
- Rolling element material
- 52100
- Temperature
- -20 ℃ to +80 ℃
- Seal type
- Closed Type
Tell us your operating requirements and required quantity.
Description
Split Bearing Units are pre-assembled systems combining split bearings (cylindrical/spherical rollers) with split housings (Plummer blocks), designed to enable rapid installation and maintenance without shaft disassembly. Ideal for heavy industries where downtime is costly.
QIBR - 01 H 403+01 B 403 EX Split Bearing Units Advantages and Applications
QIBR - 01 H 403+01 B 403 EX Split Bearing Units Characteristics
Features & benefits
Specifically for shaft suspension in conveyor systems, they prevent sagging with self-lubricating bearings. The split pillow block design allows quick maintenance, while sealed variants protect against dust in agriculture and mining.
