01 H 304+01E B 304 EX

01 H 304+01E B 304 EX · Product image

Image may differ from product. See technical specifications for details.

01 H 304+01E B 304 EX · Technical drawing

Brand
QIBR
Housing model
01 H 304
Bearing model
01E B 304 EX
Alternative brand
Cooper
Rolling element type
Roller
Measurement system
Imperial
Outer diameter
178 mm
Inner diameter
3 1/4 inch
Total width
146 mm
Bolt size
M36
Width
76 mm
Size
188 mm
Location of centre
114 mm
Number of rolling element rows
Single row
Bearing type
Hanger bearing units
Weight of bearing housing
12.0 kg
Load direction
Radial
Bearing clearances (radial)
CN/C2
Rolling element material
52100
Temperature
-20 ℃ to +80 ℃
Seal type
Closed Type

Inquiry for 01 H 304+01E B 304 EX

Tell us your operating requirements and required quantity.

Description

Split Bearing Units are pre-assembled systems combining split bearings (cylindrical/spherical rollers) with split housings (Plummer blocks), designed to enable rapid installation and maintenance without shaft disassembly. Ideal for heavy industries where downtime is costly.

QIBR - 01 H 304+01E B 304 EX Split Bearing Units Advantages and Applications

QIBR - 01 H 304+01E B 304 EX Split Bearing Units Characteristics
