F38+02 B 1200
- Brand
- QIBR
- Housing model
- F38
- Bearing model
- 02 B 1200
- Alternative brand
- Cooper
- Rolling element type
- Roller
- Measurement system
- Imperial
- Outer diameter
- 788 mm
- Inner diameter
- 12 inch
- Total width
- 296 mm
- Hole circle diameter
- 708 mm
- Width1
- 41 mm
- Location of centre
- 162 mm
- Width2
- 5 mm
- Size
- 628.65 mm
- Number of holes
- 8
- Bolt size
- 1 1/4UNC
- Weight of bearing housing
- 195.0 kg
- Load direction
- Radial
- Bearing clearances (radial)
- CN/C2
- Rolling element material
- 52100
- Temperature
- -20 ℃ to +80 ℃
- Seal type
- Closed Type
Tell us your operating requirements and required quantity.
Description
Split Bearing Units are pre-assembled systems combining split bearings (cylindrical/spherical rollers) with split housings (Plummer blocks), designed to enable rapid installation and maintenance without shaft disassembly. Ideal for heavy industries where downtime is costly.
QIBR - F38+02 B 1200 Split Bearing Units Advantages and Applications
QIBR - F38+02 B 1200 Split Bearing Units Characteristics
Features & benefits
With bolt-on flange mounting, these units provide precise axial positioning for pumps, fans, and motors. Their compact design saves space while handling radial and axial loads. Options include split inner rings for easy servicing and high-temp seals for industrial ovens.
