Worm Gears | QIBR Bearings

Specifications

Standard: GB,ASTM/AISI,ГОСТ,BS,JIS,NF,DIN / VDEh
Material: 42CrMo, 50Mn
Pitch diameter: 1.25-18 inch
Weight: 0.14-60.2 lbs
Package: QIBR/Standard Industrial Package/OEM
Brand: QIBR/OEM/Neutral
Applications: suitable for printing machines, robots and automobile production lines, etc., and is the most widely used in working conditions with high precision requirements.

QIBR Model Selection
No.	Product model	Weight	Inner diameter	Number of teeth	Gear P.C.D	Pitch
1	W10100	6.00 lbs	3/4 inch	100	10.000 inch	10 inch
2	W1020	0.70 lbs	1/2 inch	20	2.000 inch	10 inch
3	W1020D	0.65 lbs	7/8 inch	20	2.000 inch	10 inch
4	W1020Q	0.64 lbs	7/8 inch	20	2.000 inch	10 inch
5	W1030	1.50 lbs	5/8 inch	30	3.000 inch	10 inch
6	W1030D	1.30 lbs	7/8 inch	30	3.000 inch	10 inch
7	W1030Q	1.30 lbs	7/8 inch	30	3.000 inch	10 inch
8	W1040	1.80 lbs	5/8 inch	40	4.000 inch	10 inch
9	W1040D	1.60 lbs	7/8 inch	40	4.000 inch	10 inch
10	W1040Q	1.60 lbs	7/8 inch	40	4.000 inch	10 inch
11	W1050	2.80 lbs	3/4 inch	50	5.000 inch	10 inch
12	W1050D	2.90 lbs	7/8 inch	50	5.000 inch	10 inch
13	W1060	3.60 lbs	3/4 inch	60	6.000 inch	10 inch
14	W1060D	3.00 lbs	7/8 inch	60	6.000 inch	10 inch
15	W1080	4.80 lbs	3/4 inch	80	8.000 inch	10 inch
16	W12100	4.40 lbs	3/4 inch	100	8.333 inch	12 inch
17	W1218	0.28 lbs	1/2 inch	18	1.500 inch	12 inch
18	W1220	0.35 lbs	1/2 inch	20	1.667 inch	12 inch
19	W1220D	0.32 lbs	1/2 inch	20	1.666 inch	12 inch
20	W1220Q	0.32 lbs	1/2 inch	20	1.666 inch	12 inch
21	W1230	0.71 lbs	1/2 inch	30	2.500 inch	12 inch
22	W1230D	0.78 lbs	3/4 inch	30	2.500 inch	12 inch
23	W1230Q	0.38 lbs	3/4 inch	30	2.500 inch	12 inch
24	W1240	1.20 lbs	5/8 inch	40	3.333 inch	12 inch
25	W1240D	1.30 lbs	3/4 inch	40	3.333 inch	12 inch
