QGB30 and QGB10 internal clearance gauges for cylindrical roller bearings

QIBR's internal clearance gauges in the QGB 30 and QGB 10 series are meticulously engineered for precision in assessing double row cylindrical roller bearings from NN 3006 K to NN 3068 K (QGB 30 series) and single row cylindrical roller bearings from N 1010 K to NN 1020 K (QGB 10 series). Additionally, QGB 30 gauges can be effectively utilized for single row bearings in the N10 K series. These gauges excel in accurately measuring the outer envelope diameter of the roller set when rollers are in contact with the inner ring raceway, ensuring reliable dimensional checks crucial for maintaining optimal performance and assembly integrity in industrial applications.

Specifications

Product Number: QGB 3006-QGB 3068
Length: 107mm-738mm
Bearing Designation: NN 3006 KTN-NN 3068 K
Height: 175mm-665mm
Width: 36mm-122mm
Mass gauge: 2kg-64kg
Standard: GB,ASTM/AISI,ГОСТ,BS,JIS,NF,DIN/VDEh,DIN/VDEh
Brand: QIBR/OEM/Neutral
Package: Standard Export Package
Applications: Measurement

QIBR Model Selection

QIBR Model Selection
No.	Product model	Length	Height	Width	Weight	Bearing model
1	GB 1010	134 mm	207 mm	33 mm	2 kg	N 1010 K
2	GB 1011	144 mm	217 mm	35 mm	2.3 kg	N 1011 K
3	GB 1012	152 mm	225 mm	36 mm	2.7 kg	N 1012 K
4	GB 1013	157 mm	230 mm	36 mm	3 kg	N 1013 K
5	GB 1014	164 mm	237 mm	38 mm	3.2 kg	N 1014 K
6	GB 1015	168 mm	241 mm	38 mm	3.4 kg	N 1015 K
7	GB 1016	176 mm	249 mm	40 mm	4 kg	N 1016 K
8	GB 1017	185 mm	258 mm	41 mm	4.5 kg	N 1017 K
9	GB 1018	198 mm	271 mm	43 mm	5.5 kg	N 1018 K
10	GB 1019	203 mm	276 mm	43 mm	5.8 kg	N 1019 K
11	GB 1020	212 mm	285 mm	43 mm	6.5 kg	N 1020 K
12	GB 3006	107 mm	175 mm	36 mm	2 kg	NN 3006 KTN
13	GB 3007	112 mm	180 mm	37 mm	2 kg	NN 3007 K
14	GB 3008	117 mm	185 mm	39 mm	2 kg	NN 3008 KTN
15	GB 3009	129 mm	197 mm	40 mm	2.5 kg	NN 3009 KTN
16	GB 3010	134 mm	202 mm	40 mm	2.5 kg	NN 3010 KTN
17	GB 3011	144 mm	212 mm	43 mm	3.5 kg	NN 3011 KTN
18	GB 3012	152 mm	222 mm	44 mm	4 kg	NN 3012 KTN
19	GB 3013	157 mm	225 mm	44 mm	4 kg	NN 3013 KTN
20	GB 3014	164 mm	232 mm	48 mm	5 kg	NN 3014 KTN
21	GB 3015	168 mm	236 mm	48 mm	5 kg	NN 3015 KTN
22	GB 3016	176 mm	244 mm	52 mm	6 kg	NN 3016 KTN
23	GB 3017	185 mm	253 mm	53 mm	6.5 kg	NN 3017 KTN9
24	GB 3018	198 mm	266 mm	56 mm	8 kg	NN 3018 KTN9
25	GB 3019	203 mm	271 mm	56 mm	9 kg	NN 3019 KTN9

Functions of QGB30 and QGB10 internal clearance gauges for cylindrical roller bearings

1. Dimension Measurement

Ensures that the dimensions of bearings conform to design specifications.

2. Quality control

Serves as part of production quality control, helping to check and verify the accuracy of products.

Measurement using QGB30 and QGB10 internal clearance gauges for cylindrical roller bearings

QGB30 and QGB10 internal clearance gauges for cylindrical roller bearings are designed for use with double row cylindrical roller bearings ranging from NN 3006 K to NN 3068 K (QGB 30 gauges) and for use with single-row cylindrical roller bearings ranging from N 1010 K to NN 1020 K (QGB 10 gauges). In general, gauges in the QGB 30 series can also be used for single row bearings in the N10 K series.
