Flange Deep Groove Ball Bearing

Flange deep groove ball bearings are commonly used in applications where space constraints or specific mounting requirements dictate the need for a flanged design. They offer the same benefits as standard deep groove ball bearings, including high-speed capability, low friction, and versatility in handling radial and axial loads, while also providing additional features for efficient and secure installation.

Specifications

Standard: GB,ASTM/AISI,ГОСТ,BS,JIS,NF,DIN / VDEh
Material: GCr15、5200、100Cr6、SUJ2
Range of Inner Ring Dia.: 1.191mm-9.525mm
Range of Outer Ring Dia.: 3.967mm-22.225mm
Range of Weight: 0.12g-12.39g
Brand: QIBR/OEM/Neutral
Package: QIBR/Standard Industrial Package/OEM
Applications: Machine tool spindle, centrifuge, booster pump, oil pump, blower, various gearboxes, laboratory equipment

QIBR Model Selection

Showing 1 - 25 of 84 Products

Rows per page

QIBR Model Selection
No.	Product model	Outer diameter	Inner diameter	Total width	Weight	Basic dynamic load rating	Basic static load rating
1	F63800	19 mm	10 mm	7 mm	/	133 N	56 N
2	F63800 ZZ	19 mm	10 mm	7 mm	/	133 N	56 N
3	F63801	21 mm	12 mm	7 mm	/	149 N	68 N
4	F63801 ZZ	21 mm	12 mm	7 mm	/	149 N	68 N
5	F63802	24 mm	15 mm	7 mm	/	162 N	79 N
6	F63802 ZZ	24 mm	15 mm	7 mm	/	162 N	79 N
7	F63803	26 mm	17 mm	7 mm	/	175 N	90 N
8	F63803 ZZ	26 mm	17 mm	7 mm	/	175 N	90 N
9	F6700	15 mm	10 mm	3 mm	/	44 N	34 N
10	F6700 ZZ	15 mm	10 mm	4 mm	/	44 N	34 N
11	F6701	18 mm	12 mm	4 mm	/	48 N	41 N
12	F6701 ZZ	18 mm	12 mm	4 mm	/	48 N	41 N
13	F6702	21 mm	15 mm	4 mm	/	54 N	44 N
14	F6702 ZZ	21 mm	15 mm	4 mm	/	54 N	44 N
15	F6703	23 mm	17 mm	4 mm	/	53 N	50 N
16	F6703 ZZ	23 mm	17 mm	4 mm	/	53 N	50 N
17	F6704	27 mm	20 mm	4 mm	/	84 N	57 N
18	F6704 ZZ	27 mm	20 mm	4 mm	/	84 N	57 N
19	F6705	32 mm	25 mm	4 mm	/	60 N	66 N
20	F6706	37 mm	30 mm	4 mm	/	63 N	76 N
21	F6800	19 mm	10 mm	5 mm	/	133 N	56 N
22	F6800 ZZ	19 mm	10 mm	5 mm	/	133 N	56 N
23	F6801	21 mm	12 mm	5 mm	/	149 N	68 N
24	F6801 ZZ	21 mm	12 mm	5 mm	/	149 N	68 N
25	F6802	24 mm	15 mm	5 mm	/	162 N	79 N

Features and advantages of QIBR flange deep groove ball bearings

QIBR flange deep groove ball bearings are engineered to address critical operational demands in various industrial fields, offering the following key advantages:

1. Flange design

The outer ring of the bearing has a flange (protruding edge) for direct positioning or fixation. This flange is typically designed to match the bearing housing, ensuring the bearing remains aligned during installation.

The flange simplifies installation, especially in situations where the bearing cannot be fixed on both sides.

It effectively helps secure the bearing's position.

2. Simple structure

As a type of deep groove ball bearing, flange deep groove ball bearings have a simple structure, are easy to manufacture, and are capable of handling both radial and axial loads effectively.

3. Wide applicability

These bearings are suitable for handling radial loads, and axial loads, and operating at high speeds.

Flange deep groove ball bearings are commonly used in machinery where the outer ring needs to be fixed or positioned.

4. Durability

Thanks to their robust and precise structure, these bearings are durable and suitable for long-term, high-speed operation.

5. No need for additional positioning devices

The presence of the flange eliminates the need for additional positioning devices during installation, reducing assembly complexity and improving production efficiency.

Performance enhancements for QIBR flange deep groove ball bearings

1. Lubrication optimization

Advanced lubricants, such as synthetic or nano-lubricants, can reduce wear and friction, enhancing overall efficiency and durability. Proper application techniques further ensure optimal performance.

2. Raceway optimization

Precision machining of the raceway geometry, along with improved surface finish, minimizes frictional losses and enhances operational efficiency.

3. Enhanced rolling elements

Utilizing high-precision rolling elements, such as ceramic balls, improves surface hardness and reduces wear, resulting in superior performance under demanding conditions.

4. Corrosion resistance

For applications in aggressive environments, materials such as stainless steel, corrosion-resistant coatings, or surface treatment technologies can significantly improve durability.

Primary application fields of QIBR flange deep groove ball bearings

1. Electric motors

QIBR flange deep groove ball bearings are widely used in electric motors, particularly in industrial motors with heavy load requirements. Their durability and efficiency make them essential for the rotor and stator components.
