FCD

Specifications

Standard: GB,ASTM/AISI,ГОСТ,BS,JIS,NF,DIN / VDEh
Material: GCr15/100Cr6/Bearing Steel
Brand: QIBR/OEM/Neutral
Applications: Aerospace Industry, Robotics, Medical Devices, Semiconductor Manufacturing Equipment, Optical Equipment, Industrial Machinery, Automotive, etc

QIBR Model Selection

QIBR Model Selection
No.	Product model	Basic dynamic load rating	Basic static load rating	Inner diameter	Weight	Outer diameter
1	FCD112164630	12600 kN	35800 kN	560 mm	1134 kg	820 mm
2	FCD114163594	11400 kN	29700 kN	570 mm	1066 kg	815 mm
3	FCD120174640K	19300 kN	37700 kN	600 mm	1286 kg	870 mm
4	FCD138196715	15380 kN	55330 kN	690 mm	1860 kg	980 mm
5	FCD166216710	18000 kN	50000 kN	830 mm	1764 kg	1080 mm
6	FCD170230840/C9	30500 kN	69900 kN	850 mm	2529 kg	1150 mm
7	FCD190260850/YB2	29000 kN	92000 kN	950 mm	3523 kg	1300 mm
8	FCD6084300	2620 kN	6860 kN	300 mm	128 kg	420 mm
9	FCD6084300/P5	2620 kN	6860 kN	300 mm	128 kg	420 mm
10	FCD6496290	3420 kN	7200 kN	320 mm	186 kg	480 mm
11	FCD6496290/P5	3420 kN	7200 kN	320 mm	186 kg	480 mm
12	FCD6496350	6200 kN	10200 kN	320 mm	225 kg	480 mm
13	FCD6496350/P5	6200 kN	10200 kN	320 mm	225 kg	480 mm
14	FCD6496350A	6200 kN	10200 kN	320 mm	225 kg	480 mm
15	FCD6496350A/P5	6200 kN	10200 kN	320 mm	225 kg	480 mm
16	FCD6896350	5850 kN	10327 kN	340 mm	230 kg	480 mm
17	FCD6896350/P5	5850 kN	10327 kN	340 mm	230 kg	480 mm
18	FCD6896350A	5850 kN	10327 kN	340 mm	230 kg	480 mm
19	FCD6896350A/P5	5850 kN	10327 kN	340 mm	230 kg	480 mm
20	FCD74104380	6550 kN	10600 kN	370 mm	253 kg	520 mm
21	FCD74104380/P5	6550 kN	10600 kN	370 mm	253 kg	520 mm
22	FCD76108400	4630 kN	12600 kN	380 mm	291 kg	540 mm
23	FCD76108400/P5	4630 kN	12600 kN	380 mm	291 kg	540 mm
24	FCD96136500	11000 kN	15600 kN	480 mm	607 kg	680 mm
25	FCD96140400	6600 kN	15100 kN	480 mm	508 kg	700 mm

Features and advantages of QIBR four-row cylindrical roller bearing FCD series

QIBR four-row cylindrical roller bearing FCD series solves multiple key problems in various fields, which are mainly reflected in the following aspects:

1. QIBR four-row cylindrical roller bearing FCD series has high rigidity

QIBR four-row cylindrical roller bearing FCD series has relatively strong rigidity due to the dense contact between the roller and the inner ring, which can provide stable support and precise operation.

2. QIBR four-row cylindrical roller bearing FCD series has compact design

QIBR four-row cylindrical roller bearing FCD series adopts full-fill design, with a large number of rollers and relatively small radial dimensions, which can be used in places with limited space.

3. QIBR four-row cylindrical roller bearing FCD series has high load-bearing capacity

QIBR four-row cylindrical roller bearing FCD series has almost every roller in contact with the load surface, so the load-bearing capacity of this bearing is very high, especially suitable for applications with heavy loads.

4. Energy saving of QIBR four-row cylindrical roller bearing FCD series

QIBR four-row cylindrical roller bearing FCD series reduces the friction between the outer ring and the inner ring: the design of direct contact between the roller and the inner ring reduces the friction between the outer ring and the inner ring, further reducing energy loss.

The performance improvement and solution of QIBR four-row cylindrical roller bearing FCD series

1. Improve corrosion resistance

For bearings that need to work in harsh environments, especially when used in humid, chemical media or salt spray environments, QIBR four-row cylindrical roller bearing FCD series can use stainless steel or other corrosion-resistant materials, or perform special anti-corrosion treatment on the bearing surface (such as electroplating, coating, etc.) to extend its service life.

2. Optimize rollers

QIBR four-row cylindrical roller bearing FCD series can reduce contact stress, improve load capacity and durability by optimizing the roller shape. Roller surface treatment can reduce friction, improve rolling accuracy and load capacity, and extend the service life of bearings.

3. Improve manufacturing accuracy

QIBR four-row cylindrical roller bearing FCD series adopts advanced foreign processing equipment and processes, such as precision grinding, super-finishing, etc., to improve the geometric accuracy of inner and outer rings and rollers, reduce processing errors, and thus improve the rotation accuracy and roughness of bearings.
