Double row full complement cylindrical roller bearings without outer ring

Specifications

Standard: GB,ASTM/AISI,ГОСТ,BS,JIS,NF,DIN / VDEh
Material: GCr15/ 100Cr6/ Bearing Steel
Range of Inner Ring Dia.: 18-140mm
Range of Outer Ring Dia.: 32.3-197.82mm
Range of Weight: -
Brand: QIBR/OEM/Neutral
Package: QIBR/Standard Industrial Package/OEM
Applications: gearboxes, machine tools, and heavy machinery, etc

QIBR Model Selection

QIBR Model Selection
No.	Product model	Inner diameter	Outer envelope circle	Width	Chamfer dimension2	Total width
1	2164	38 mm	52.95 mm	22 mm	0.3 mm	28 mm
2	2164/P5	38 mm	52.95 mm	22 mm	0.3 mm	28 mm
3	2168	40 mm	57.81 mm	28 mm	0.3 mm	34 mm
4	2168/P5	40 mm	57.81 mm	28 mm	0.3 mm	34 mm
5	2178	30 mm	49.6 mm	18 mm	0.3 mm	24 mm
6	2178/P5	30 mm	49.6 mm	18 mm	0.3 mm	24 mm
7	2179	40 mm	61.74 mm	20.9 mm	0.3 mm	28 mm
8	2179/P5	40 mm	61.74 mm	20.9 mm	0.3 mm	28 mm
9	2180	40 mm	61.74 mm	24.9 mm	0.3 mm	32 mm
10	2180/P5	40 mm	61.74 mm	24.9 mm	0.3 mm	32 mm
11	2183-2439	32 mm	46.6 mm	22 mm	0.3 mm	28 mm
12	2183-2439/P5	32 mm	46.6 mm	22 mm	0.3 mm	28 mm
13	2188	40 mm	61.74 mm	20.9 mm	0.3 mm	28 mm
14	2188/P5	40 mm	61.74 mm	20.9 mm	0.3 mm	28 mm
15	2190-2465	50 mm	72.33 mm	33.1 mm	1.1 mm	40 mm
16	2190-2465/P5	50 mm	72.33 mm	33.1 mm	1.1 mm	40 mm
17	2191-2444	55 mm	83.54 mm	39 mm	1.1 mm	46 mm
18	2191-2444/P5	55 mm	83.54 mm	39 mm	1.1 mm	46 mm
19	2198	30 mm	49.6 mm	20 mm	0.3 mm	26 mm
20	2198/P5	30 mm	49.6 mm	20 mm	0.3 mm	26 mm
21	2400	24 mm	40.25 mm	20 mm	0.3 mm	26 mm
22	2400/P5	24 mm	40.25 mm	20 mm	0.3 mm	26 mm
23	2401	44 mm	62.97 mm	30.9 mm	0.3 mm	37 mm
24	2401/P5	44 mm	62.97 mm	30.9 mm	0.3 mm	37 mm
25	2412	42 mm	60.75 mm	30.9 mm	0.3 mm	37 mm

Features and advantages of QIBR double row full complement cylindrical roller bearings without outer ring

QIBR double row full complement cylindrical roller bearings without outer ring solves several key problems in various fields, which are mainly reflected in the following aspects:

1. QIBR double row full complement cylindrical roller bearings without outer ring High rigidity

QIBR double row full complement cylindrical roller bearings without outer ring Due to the dense contact between the roller and the inner ring, the rigidity of this bearing is relatively strong, which can provide stable support and precise operation.

2. QIBR double row full complement cylindrical roller bearings without outer ring Compact design

QIBR double row full complement cylindrical roller bearings without outer ring adopts a full-fill design, with a large number of rollers and a relatively small radial size, which can be used in places with limited space.

3. QIBR double row full complement cylindrical roller bearings without outer ring has high load-bearing capacity

QIBR double row full complement cylindrical roller bearings without outer ring Each roller almost contacts the load surface, so this bearing has a very high load-bearing capacity, which is particularly suitable for applications with heavy loads.

4. QIBR double row full complement cylindrical roller bearings without outer ring save space

The characteristic of QIBR double row full complement cylindrical roller bearings without outer ring is that it does not use an outer ring, but bears the load through the contact between the roller and the inner ring. This design makes the bearing more suitable for some applications with limited space.

5. QIBR double row full complement cylindrical roller bearings without outer ring save energy

QIBR double row full complement cylindrical roller bearings without outer ring reduce the friction between the outer ring and the inner ring: the design of direct contact between the roller and the inner ring reduces the friction between the outer ring and the inner ring, further reducing energy loss.

The performance improvement and solution of QIBR double row full complement cylindrical roller bearings without outer ring

1. Improve corrosion resistance

For bearings that need to work in harsh environments, especially when used in humid, chemical media or salt spray environments, QIBR double row full complement cylindrical roller bearings without outer ring can use stainless steel or other corrosion-resistant materials, or perform special corrosion-resistant treatment on the bearing surface (such as electroplating, coating, etc.), thereby extending its service life.
