YRT&YRTC

Specifications

Standard

GB,ASTM/AISI,ГОСТ,BS,JIS,NF,DIN / VDEh

Material

52100/100Cr6/SUJ2/Stainless Steel

Brand

QIBR/OEM/Neutral

Package

QIBR/Standard Industrial Package/OEM

Inner diameter

50~1030mm

Outer diameter

126~1300mm

Applications

Aerospace Industry, Robotics, Medical Devices, Semiconductor Manufacturing Equipment, Optical Equipment, Industrial Machinery, Automotive, etc

QIBR Model Selection

QIBR Model Selection
No.	Product model	Inner diameter	Outer diameter	Weight	Overall height	Number of holes2
1	YRT100	100 mm	185 mm	4.1 kg	38 mm	3
2	YRT120	120 mm	210 mm	5.3 kg	40 mm	3
3	YRT150	150 mm	240 mm	6.2 kg	40 mm	3
4	YRT180	180 mm	280 mm	7.7 kg	43 mm	3
5	YRT200	200 mm	300 mm	9.7 kg	45 mm	3
6	YRT260	260 mm	385 mm	18.3 kg	55 mm	3
7	YRT325	325 mm	450 mm	25 kg	60 mm	3
8	YRT395	395 mm	525 mm	33 kg	65 mm	3
9	YRT460	460 mm	600 mm	45 kg	70 mm	3
10	YRT50	50 mm	126 mm	1.6 kg	30 mm	/
11	YRT80-TV	80 mm	146 mm	2.4 kg	35 mm	/
12	YRTC1030	1030 mm	1300 mm	375 kg	145 mm	6
13	YRTC580	580 mm	750 mm	89 kg	90 mm	6
14	YRTC650	650 mm	870 mm	170 kg	122 mm	6
15	YRTC850	850 mm	1095 mm	253 kg	124 mm	6

Characteristics and advantages of QIBR rotary table bearing YRT series

QIBR rotary table bearing YRT series has multiple significant characteristics and advantages, which can solve key problems in various fields, mainly reflected in the following aspects；

1. QIBR rotary table bearing YRT series has the characteristic of high-precision rotation

QIBR rotary table bearing YRT series can provide extremely high rotational accuracy and control the rotation angle at the micrometer level. Ensure that the equipment can achieve very precise position control during operation.

2. QIBR rotary table bearing YRT series has the characteristic of combined composite bearing capacity

QIBR rotary table bearing YRT series can simultaneously withstand radial loads, axial loads, and tilting loads, making it suitable for applications that can withstand multi-directional loads, providing stable support and rotation.

3. QIBR rotary table bearing YRT series has the characteristic of high rigidity

QIBR rotary table bearing YRT series design has high rigidity and can effectively suppress deformation caused by load changes. Maintain rotational accuracy and mechanical structure stability, and reduce errors caused by insufficient rigidity.

4. QIBR rotary table bearing YRT series has the characteristic of optimized structural design

QIBR rotary table bearing YRT series are designed with installation holes on the inner and outer rings, which can simplify the installation process of the bearings and improve installation efficiency.

5. QIBR rotary table bearing YRT series has the characteristics of low friction and high efficiency

The QIBR rotary table bearing YRT series reduces bearing friction torque, making it suitable for use with low driving torque requirements and improving the overall operating efficiency of the equipment.

Performance improvement and solution of QIBR rotary table bearing YRT series

1. Effectively improve the bearing load capacity

The QIBR rotary table bearing YRT series selects high-strength materials to improve the bearing's ability to withstand heavy loads and impact loads. By improving the internal structural design, the load-bearing capacity of the bearing is enhanced, and the anti fatigue performance is strengthened.

2. Improve manufacturing accuracy

The QIBR rotary table bearing YRT series uses high-precision machining equipment and technology to reduce manufacturing tolerances and improve the overall accuracy of the bearing. Strengthen quality control in the production process to ensure that each bearing meets high-precision standards.

3. Personalized design
